COMPONENT HUNT

I request thy aid.

My plans for a Revenant are complete, so what I need now is the primary components so I can get cracking.
I am thus asking for you help in dreaming up where I can find the necessary parts.

What I need to start off with are a series of concentric rings, thats rings within rings, as such:




The largest ring should be no more than 10" in diameter.
Ideally, there would be about 12 rings, with the smallest being no smaller than 3 or 4" in diameter.

Plastic of an easy to use metal are of course preferred.

Also, not too expensive, and weight might be an issue.



In my brain, I'm imagining there's a toy, or strange house decoration that would fit the bill.
Can't find anything specific off the top of my head though, and thus do I turn to you.

Thanks in advance for all useful suggestions.
